WuzAPI Documentation

POST /session/connect

Connects to WhatsApp servers. If there is no previous session, you will need to scan a QR code.

Body Parameters:

Request Example:

{
  "Subscribe": ["Message", "ReadReceipt"],
  "Immediate": true
}

Response:

{
  "code": 200,
  "data": {
    "details": "Connected!",
    "events": "Message,ReadReceipt",
    "jid": "5491155555555.0:53@s.whatsapp.net",
    "webhook": "https://some.site/webhook?request=parameter"
  },
  "success": true
}

POST /session/disconnect

Disconnects from WhatsApp servers without ending the session.

Response:

{
  "code": 200,
  "data": {
    "Details": "Disconnected"
  },
  "success": true
}

POST /session/logout

Ends the connection and terminates the session, requiring QR scanning again on next connection.

Response:

{
  "code": 200,
  "data": {
    "Details": "Logged out"
  },
  "success": true
}

GET /session/status

Gets the current connection and session status.

Response:

{
  "code": 200,
  "data": {
    "Connected": true,
    "LoggedIn": true
  },
  "success": true
}

GET /session/qr

Gets the QR code for scanning in the WhatsApp app.

Response:

{
  "code": 200,
  "data": {
  },
  "success": true
}

GET /webhook

Gets the configured webhook and subscribed events.

Response:

{
  "code": 200,
  "data": {
    "subscribe": ["Message", "ReadReceipt"],
    "webhook": "https://example.net/webhook"
  },
  "success": true
}

POST /webhook

Configures a webhook to receive events.

Body Parameters:

Request Example:

{
  "webhook": "https://example.net/webhook",
  "events": ["Message", "ReadReceipt"]
}

Response:

{
  "code": 200,
  "data": {
    "webhook": "https://example.net/webhook",
    "events": ["Message", "ReadReceipt"]
  },
  "success": true
}

PUT /webhook

Updates the webhook configuration. Can update only the URL, only the events, or both.

Body Parameters:

Request Examples:

// Atualizar apenas eventos
{
  "events": ["Message", "Receipt", "GroupInfo"],
  "active": true
}

// Atualizar apenas URL
{
  "webhook": "https://novo-endpoint.com/webhook",
  "active": true
}

// Desativar webhook
{
  "active": false
}

DELETE /webhook

Removes the webhook and clears the event configuration.

Response:

{
  "code": 200,
  "data": {
    "message": "Webhook removed successfully"
  },
  "success": true
}

POST /chat/send/text

Sends a text message to a contact or group.

Body Parameters:

Request Example:

{
  "Phone": "5491155553935",
  "Body": "Olá, como você está?",
  "Id": "ABCDABCD1234",
  "ContextInfo": {
    "StanzaId": "3EB06F9067F80BAB89FF",
    "Participant": "5491155553935@s.whatsapp.net"
  }
}

Response:

{
  "code": 200,
  "data": {
    "Details": "Sent",
    "Id": "ABCDABCD1234",
    "Timestamp": "2023-03-24T15:49:08-03:00"
  },
  "success": true
}

POST /chat/send/image

Sends an image to a contact or group.

Body Parameters:

GET /chat/history

Recover the message history of a specific chat. Returns the messages in reverse chronological order (most recent first).

Parâmetros de Query:

Request Example:

GET /chat/history?chat_jid=5491155553935@s.whatsapp.net&limit=10

Resposta de Sucesso:

{
  "code": 200,
  "success": true,
  "data": [
    {
      "id": 1,
      "user_id": "abc123def456",
      "chat_jid": "5491155553935@s.whatsapp.net",
      "sender_jid": "5491155554444@s.whatsapp.net",
      "message_id": "3EB0C767D26A1B5F7C83",
      "timestamp": "2023-12-01T15:30:00Z",
      "message_type": "text",
      "text_content": "Olá, como você está?",
      "media_link": ""
    },
    {
      "id": 2,
      "user_id": "abc123def456",
      "chat_jid": "5491155553935@s.whatsapp.net",
      "sender_jid": "5491155553935@s.whatsapp.net",
      "message_id": "4FB1D878E37B2C6G8D94",
      "timestamp": "2023-12-01T15:25:00Z",
      "message_type": "image",
      "text_content": "Veja esta foto!",
      "media_link": "https://example.com/media/image123.jpg"
    }
  ]
}

Possible Errors:

POST /user/check

Checks if phone numbers have WhatsApp.

Body Parameters:

Request Example:

{
  "Phone": ["5491155553934", "5491155553935"]
}

Response:

{
  "code": 200,
  "data": {
    "Users": [
      {
        "IsInWhatsapp": true,
        "JID": "5491155553934@s.whatsapp.net",
        "Query": "5491155553934",
        "VerifiedName": "Company Name"
      },
      {
        "IsInWhatsapp": false,
        "JID": "5491155553935@s.whatsapp.net",
        "Query": "5491155553935",
        "VerifiedName": ""
      }
    ]
  },
  "success": true
}

GET /group/list

Lists all groups to which the account is linked.

Response:

{
  "code": 200,
  "data": {
    "Groups": [
      {
        "AnnounceVersionID": "1650572126123738",
        "DisappearingTimer": 0,
        "GroupCreated": "2022-04-21T17:15:26-03:00",
        "IsAnnounce": false,
        "IsEphemeral": false,
        "IsLocked": false,
        "JID": "120362023605733675@g.us",
        "Name": "Super Group",
        "NameSetAt": "2022-04-21T17:15:26-03:00",
        "NameSetBy": "5491155554444@s.whatsapp.net",
        "OwnerJID": "5491155554444@s.whatsapp.net",
        "ParticipantVersionID": "1650234126145738",
        "Participants": [
          {
            "IsAdmin": true,
            "IsSuperAdmin": true,
            "JID": "5491155554444@s.whatsapp.net"
          },
          {
            "IsAdmin": false,
            "IsSuperAdmin": false,
            "JID": "5491155553333@s.whatsapp.net"
          }
        ],
        "Topic": "",
        "TopicID": "",
        "TopicSetAt": "0001-01-01T00:00:00Z",
        "TopicSetBy": ""
      }
    ]
  },
  "success": true
}

GET /newsletter/list

Lists all subscribed newsletters.

Response:

{
  "code": 200,
  "data": {
    "Newsletter": [
      {
        "id": "120363144038483540@newsletter",
        "state": {"type": "active"},
        "thread_metadata": {
          "creation_time": "1688746895",
          "description": {
            "text": "WhatsApp's official channel. Follow for our latest feature launches, updates, exclusive drops and more."
          },
          "name": {"text": "WhatsApp"},
          "picture": {"type": "IMAGE"},
          "subscribers_count": "0"
        },
        "viewer_metadata": {"role": "subscriber"}
      }
    ]
  },
  "success": true
}

GET /admin/users

Lists all users registered in the system.

Headers:

Response:

{
  "code": 200,
  "data": [
    {
      "id": 1,
      "name": "John",
      "token": "1234ABCD",
      "webhook": "https://example.com/webhook",
      "jid": "5491155553934@s.whatsapp.net",
      "qrcode": "",
      "connected": true,
      "expiration": 0,
      "events": "Message,ReadReceipt"
    }
  ],
  "success": true
}

GET /s3/config

Gets the current S3 configuration.

Response:

{
  "code": 200,
  "data": {
    "endpoint": "https://s3.amazonaws.com",
    "bucket": "meu-bucket",
    "region": "us-east-1",
    "path_prefix": "uploads/whatsapp/",
    "force_path_style": false
  },
  "success": true
}

PUT /s3/config

Configures S3 storage for this instance.

Body Parameters:

Request Example:

{
  "endpoint": "https://s3.amazonaws.com",
  "access_key": "AKIAIOSFODNN7EXAMPLE",
  "secret_key": "wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY",
  "bucket": "meu-bucket-whatsapp",
  "region": "us-east-1",
  "path_prefix": "uploads/",
  "force_path_style": false
}

Response:

{
  "code": 200,
  "data": {
    "message": "S3 configuration saved successfully"
  },
  "success": true
}

POST /s3/test

Tests the connection to S3 using the provided configuration.

Body Parameters:

Same parameters as PUT /s3/config endpoint

Response:

{
  "code": 200,
  "data": {
    "message": "S3 connection test successful"
  },
  "success": true
}

GET /proxy/config

Gets the current proxy configuration.

Response:

{
  "code": 200,
  "data": {
    "proxy_url": "socks5://proxy.example.com:1080",
    "username": "user",
    "bypass_list": ["localhost", "127.0.0.1", "*.local"]
  },
  "success": true
}

PUT /proxy/config

Configures the proxy for this instance.

Body Parameters:

Request Example:

{
  "proxy_url": "socks5://proxy.example.com:1080",
  "username": "usuario",
  "password": "senha123",
  "bypass_list": ["localhost", "127.0.0.1", "*.local", "192.168.*"]
}

Response:

{
  "code": 200,
  "data": {
    "message": "Proxy configuration saved successfully"
  },
  "success": true
}

POST /proxy/test

Tests the connection through the configured proxy.

Body Parameters:

Same parameters as PUT /proxy/config endpoint (except bypass_list)

Response:

{
  "code": 200,
  "data": {
    "message": "Proxy connection test successful",
    "response_time": "245ms"
  },
  "success": true
}
